ETi-VP700 /VP800 PH Electrode

    Features:
    1. The electrode is disposable and cheap. Through the experiment, we found out that its service life and efficiency is better than the ones of industrial glass electrode.
    2. Because the electrode will be immersed into the electrode, the protective casing is reusable.
    3. While the pressure is higher than 40 PSI, the pipe of electrode must be sealed completely to prevent from the leakage because the protective casing is not reusable.
    4. Double layers of solid polymer reference electrode with internal pressurization can prevent from the electrolyte leakage and pollution to increase the service life of electrode.
    5. Electrode may directly connect with the pipe or could be used in the water.
    Application Range: Industrial process, wastewater and recycled water.

内容说明

 Specification

Temperature

0~80 °C

Operation Range

PH 0 ~ 14

Pressure

80 PSI at 25 °C



Ceramic hole

Ceramic core

Reference System

Dual salt bridge electrolyte system used for solid polymer electrolyte.

Cable Length

5m or 10m (optional)

Electrode Appearance and Dimension

Epoxy materials, 12 X 120mm

Electrode Protective Casing

Covering Material

PVC or Ryton® body with Viton® O-Rungs

Pipe Joint

3/4 inch MNPT
